OUR STORY

Since 1929.

Dayton Rogers has been turning metal into precision parts American industries have depended on for nearly a century. We are still privately held, still family-led, and still doing it the way that earned the company its reputation: engineer the part for manufacturing, run production in one quality system, and stand behind it.

PRIVATELY HELD

FAMILY-LED

ONE ROOF

Original location in 1929

MINNEAPOLIS, MN

EST.

Original location in 1929

MINNEAPOLIS, MN

EST.

We wrote the book on metal forming. Literally.

Generations of our engineers compiled what they learned into the Metalforming Design Handbook, the volume the industry knows as the Red Book. Design guidelines, formulas, and hard-won rules, in one reference engineers across the industry still keep on the desk.

That handbook is the clearest proof of how we think about your part: design authority first. The same engineering team that wrote the reference is the team that reviews your drawing for manufacturing, so cost and lead time get solved before a die is ever cut.

Things Learned from over
90 Year making Metal Stampings
TABLE OF CONTENTS
1.How to Use Short Run Stampings5
2.Tolerances8
3.Edge Conditions9
4.Blank Design10
5.Piercing Round Holes11
6.Definition of Punched Holes13
7.Specification and Measurement of Round Holes13
8.Recommended Minimum Ratios of Punched Holes14
9.Spacing of Hole Edge to Part Edge and Adjacent Holes15
10.Piercing — Adjacent to Bends16
11.Definition and Limits of Extruded Holes17
12.Common Methods of Countersinking17
13.Elements of Formed Stampings18
14.Specifications and Measurement of Formed Parts19
15.Position of the Form20
16.Height of the Form21
17.Distortion and Interference of Forming22
18.Edge Conditions of Formed Parts24
19.Styles of Embossing24
20.Specification and Measurement of Embossed Parts25
21.Recommended Limits of Embossed Parts26
22.Specifications and Characteristics of Drawn Parts27
23.Edge Condition of Drawn Parts28
24.Surface and Characteristic Conditions of Drawn Shapes29
25.Limits for Burrs30
26.Measurement and Limits of Flatness30
27.Dimensioning Practices for Turret Press31
28.Dimensioning Practices for Press Brake32
29.Laser Cutting33
30.Laser Considerations33
31.Carbon Steel Strip35
32.Minimum Bend radii for Aluminum36
33.Tap Drill Sizes — Machine Screw Threads37
34.Pierced Hole Size Ctsk Diameter for 82° Screws38
35.Tonnage Formula39
Dayton Rogers Mfg. Co. acknowledges, with gratitude, selected illustrations
and editorial material supplied by Precision Metalforming Association.
Note: All dimensions are in English unless otherwise specified.
2
www.daytonrogers.com
METALFORMING
DESIGN HANDBOOK
COST EFFECTIVE DESIGN PRINCIPLES
In the beginning
Dayton Rogers was the only
short run stamping company.
Put our years of experience at your fingertips.
You get quality products, reliable service, and fast
delivery — guaranteed — from Dayton Rogers.
Questions? Contact us . . .
You can count on Dayton Rogers.
Four generations already have.

HERITAGE

Nearly a century of precision.

1929

Dayton Rogers is founded.

Precision metal stamping, from Minneapolis.

THE RED BOOK

We author the Metalforming Design Handbook.

Our engineers’ design rules become an industry reference, the Red Book.

FOUR PLANTS

Dayton Rogers grows to four U.S. facilities.

Minneapolis, MN; Columbus / Obetz, OH; Arlington, TX; and Newberry, SC, placed to keep lead times short.

2025

Stephanie Lowry is named Chief Executive Officer.

The same year she’s recognized as a 2025 Woman of Excellence in Metal Forming & Fabricating by the Precision Metalforming Association.

IN MOTION

Sixty seconds
on the floor.

Four U.S. plants, one quality system, filmed where the work happens: progressive and deep-draw stamping, laser and brake-press fabrication, robotic welding, powder coating, and assembly.

Minneapolis, MN · Columbus, OH · Arlington, TX · Newberry, SC

Segment trailer · 1:00

LEADERSHIP

A receptionist who became CEO.

Stephanie Lowry, Chief Executive Officer of Dayton Rogers
Stephanie Lowry joined Dayton Rogers as a receptionist. In 2025, she was named its Chief Executive Officer.

It’s the kind of story a family-led, woman-led manufacturer that’s been at this since 1929 can tell, because it’s true, not because it polls well. Ron Lowry, Owner and Chairman, continues to guide the company alongside her. Together they lead a business that still answers to a family, not a fund.

In 2025, Stephanie was named a Woman of Excellence in Metal Forming & Fabricating by the Precision Metalforming Association, where she is a past chair of the Southeast District. In 2026, she was honored at the SCBIZ Leaders in Business & Finance Awards.

Stephanie Lowry

Chief Executive Officer · Dayton Rogers

Ron Lowry

Owner & Chairman of the Board

Mike Ingalls

Executive Director of Engineering & Development

Marvin Wreh

Executive Director of Operations

Darrin Carlson

Chief Financial Officer

HOW WE WORK

A total project partner.

A stamper, a finisher, and an assembler under one partner who runs the whole part.

ONE ROOF

Prototype through production

Your part runs on the same line, in the same quality system, from first article to full volume.

ENGINEER-FIRST

DFM by design

We optimize for manufacturing before tooling, and we help you move between fabrication and stamping as volume and cost change.

PERSONAL

Real service

Customers stay because we’re prompt, responsive, and accountable, not because they’re locked in.

U.S. PLANTS

Four U.S. plants

Four U.S. facilities, privately held, family-led, since 1929.

CAREERS

Open roles.

Four U.S. plants. Toolmakers, operators, and engineers who like making parts that last.

Tool & Die Operator

Blaine, MN

Full-time

Tooling

Pay: $25.00–$35.00/hour. Schedule: 10-hour shifts, 4x10. Maintain, repair, and build tools to meet customer specifications safely and efficiently. Perform basic machining, disassembly, repair, and reassembly tasks under supervision.

Press Room Lead 2nd Shift

Blaine, MN

Full-time

Stamping

Pay: $25.00–$29.00/hour, based on experience. Schedule: Monday–Thursday, 6:00 a.m.–4:30 p.m. Dayton Rogers is seeking an experienced Press Room Lead to help oversee daily production and support our Press Room team. This position coordinates employees and production activities to ensure parts are produced safely, efficiently, and according to customer specifications.

Press Room Lead 1st Shift

Blaine, MN

Full-time

Stamping

Pay: $25.00–$29.00/hour, based on experience. Schedule: Monday–Thursday, 6:00 a.m.–4:30 p.m. Dayton Rogers is seeking an experienced Press Room Lead to help oversee daily production and support our Press Room team. This position coordinates employees and production activities to ensure parts are produced safely, efficiently, and according to customer specifications.

Turret Operator

Blaine, MN

Full-time

Fabrication

Pay: $18.00–$22.00/hour. Schedule: Day shift. We are looking for a dependable Turret Operator/Fabricator to join our manufacturing team. In this role, you will operate fabrication equipment to produce quality parts according to customer specifications while maintaining a safe and efficient work environment.

WORK WITH US

Put 1929 to work on your part.

Send a production drawing or describe what you are sourcing. Our engineers review every RFQ for DFM and process path, prototype through production.
